Setting up Caterpillar Communication Adapter

Requirements 7X1700
– Caterpillar Communication Adapter Group

Note:
You may use the 7X1701 Caterpillar Communication Adapter; however, it is no longer available for purchase from Caterpillar.

Also requires:

15-1

Instructions
To set up the Communication Adapter, perform the following steps:

Step 1
Connect the 7X-1425 RS232 cable to an available Serial Port on your PC and to the Service Tool connector on the Communication Adapter.

Step 2
Connect the 139-4166 Unicable to the Control connector on the Communication Adapter and to the service
connector on the product that you are servicing. You are now ready to start your Car Diagnostic Tool.

Note:
Caterpillar Communication Adapter (7X1701) does not support J1939 data link.

Requirements
MPSI Pro-Link? 9000 (only for On Highway Truck engines and certain commercial applications) This package also requires the following equipment:

Description
MPSI PC/Terminal Cable
MPSI Caterpillar Cartridge (version 1.07 or greater)

Note:
If programming a 3126 HEUI, it is recommended you disconnect the power to the Allison transmission and re-connect with Pro-Link.

Instructions
Perform the following steps to set up the Pro-Link 9000:

Step 1
Insert the MPSI Caterpillar Cartridge in the Pro-Link?9000.

Step 2
Connect the Pro-Link 9000 to your PC’s serial port using the MPSI PC/Terminal cable.

Step 3
Connect the Pro-Link 9000 to the product and turn the ignition key of the vehicle on to power the Pro-Link.

Step 4
Select Pro-Link from the main menu or push the “Func” key to recall data if no engine data is received.

Step 5
Select the Com Adapter Link function from the Pro-Link menu, and push “Enter” to initiate the Com Adapter Link mode. The Pro-Link will display a screen showing that the Com Adapter Link is active. You are now ready to start the Caterpillar SIS.

How to Install Ford IDS V108.01 Full without Activation

Latest Ford IDS V108.01 Full Software for Ford VCM II support online programming released on Jan. 2018.

Software Version: 108.01, no need activation

Operating system: Windows XP/Windows 7 32/64 bit

Multi-language:

5-0

Tested with all VCM2 SP177 series,  Ford VCM2 2-in-1 clone and VXDIAG VCX NANO Ford: Never failed!!

Online programming: Supported! but you should have an account yourself.

Ford IDS v108.01 function: Confirmed!

1.Able to download the very latest calibration files/software from Ford server if the network connection available at the time of connecting to vehicles

2.Read and decode fault codes

3.Delete fault codes

4.Display System current parameters in digital form

5.Combined displaying of data

6.Logs Keeping: write and keep of digital parameters in memory

7.Special functions: changing of permissible seeting of blocks, programming etc.

FAQ:

Q: Whether it can work with Ford VCM 1 Clone?

A: Yes, it can work with Ford VCM 1 clone

Q: Is this vmware or native

A: This is native, install on new and clean windows xp/7

How to install Ford IDS V108 step by step?

Preparation:

1. Please backup the important files on the desktop and disk C because the next operation will cover the content in the disk C.

2.Disable both local area and wireless network connection

3. If your computer hard drive only has one partition, please prepare a 16 GB U flash drive, if has 2 partitions, please unzip the software of CD into another partition except disk C

Step 1: Recover System
Open Software D (Disk D)

5-1
Create new folder Ford 108

5-2
Copy all zip file on Ford 108-2 software CD to Ford 108 folder
Eject Ford 108-2 DVD-ROM to DVD/CD-RW Drive

5-3
Copy all contents to Ford 108 folder again
Extract ford108.part01 zip files to Ford 108 folder

5-4
Then delete all other zip files, ford108.part01-ford108.part33
(only 3 files left)
Open Ghost 8.0

5-5
Recover system, choose destination D:/Ford 108/ford108.GHD
Restart computer and recover system

5-6

Step 2: Install Ford IDS 108 Setup

5-7

Run Ford Module Programming Limit as Administrator
Ford Extension Success, press OK
Module programming has been extended to 2018/05.26

5-8
Click on Start menu->All Program->Bosch->VCM Manager (Ford-VCM-II)
If system prompt PC software initialization error, press OK to ignore
Open Disk C/Progam Files/Ford Motor Company->IDS->Runtime->install3rdparty->
ETAS, Run setup as Administrator

5-9

5-10

Install Bosch VCI software Ford VCM II

5-11
click Next
Select Remove Bosch VIC software from your computer, click Next

5-12
Press Remove
Click Finish
Again run setup as Administrator
click Next

5-13
Ready to install the program
Click Finish

Install setup completed.

Step 3: Make Connection
Click Start menu->VCI Manger (Ford-VCM-II)

5-14
Connect VCMII with computer follow the diagram below

5-15
Open Computer->Manager->Device Manger->Network adapters->ETAS VCI USB RNDIS Device
to check connection is built

5-16

Open Network and Sharing center->Change adapter settings
Make sure you have disable both local area and wireless network connection

5-17

Step 4: Run software

Open Ford IDS v108 software on desktop

5-18

Network test, gathering vehicle data

5-19
check language options, programming modules and options

5-20

5-21

Done.

How to use a OBD2 Scanner 2018

1

Learning to use a good automotive OBD2 Scanner is one of the best ways you can continually invest in the health of your car. In addition, it can help you in protecting hundreds or thousands of dollars in auto maintenance. The OBD2 scanner is the second version of the On-Board Diagnostics, which monitors engine functions.

In the event of a problem with the engine, the “Engine Check” light appears. The OBD2 scanner can access the resulting crash codes in the vehicle’s diagnostic computer or even the train control module. This handheld computer can simply connect to the media stated in 1996 and later. Early cars use old diagnostic techniques that vary according to the manufacturer of the vehicle.

OBD2 scanning engines can be used by any car owner plus a whole array of costs and functions. Professional mechanics are more likely to reach the general reader. Regardless of the type of person reading the code you have the way it really is used is pretty much the same.

How to use OBD2 Scanner tips

First, you will need the cable to connect to the scanner or PC with the OBD2 software system. Most scanners are universal because they will read the most popular codes, but some of these may only use certain types of vehicles so make sure that the scanner you are working with is the most common your Car. Make sure the car’s engine is turned off before linking you.

Locate the OBD2 system connector plug location. If your vehicle certainly complies with the OBD2 protocol, it has a 16-pin sub-connector that is usually close to the center console for the driver side. Different vehicles may have different positions, such as under the steering wheel, behind the ashtray, between the front seats or under the driver’s seat. Instant online checks will help you find the location for the particular car in case it is not easily noticeable.

Check the connection plug of a particular vehicle to ensure that all the necessary pins can be found. Almost all of them are 4 plus 5 pin for grounding and 16 pin for power supply.

Connect your OBD2 scanner to your car’s computer. Wiring your 16-pin connector at one end should hang up the women’s port on your car. Connect the other end of the cable to your scanner afterwards.

An alternative to a handheld scanner is to connect to a computer that has an OBD2 software system attached to it. You will need a wire with a 16-pin connector with one end attached to another USB port to attach to your computer. Bluetooth connectivity is possible so that this application is also possible.

Once you have connected it can take a short amount of time for the reader to initialize. Your scanner can check your car’s computer to find out what protocols are often needed as well as make connections. Specific scanners read the error codes stored in the car’s computer and displayed on the screen.

To explain the specific code you may have to seek advice from the manual for the automobile although some scanners provide information for the underlying code. Some scan device manufacturers provide inputting applications that will translate program code and provide repair procedures that are defined on that code.

Step by step to properly use the OBD2 scanner

how to connect obd2 scanner to DLC

Step 01: Make sure the car is turned off. Locate the data link underneath the steering wheel. It’s a wall outlet that allows the use of a special diagnostic computer, which most vehicles are sure to drive.

Step 02: Connect the OBD2 scanner to the Data Link Connector. The scanner cord in a 16-pin plug should match the natural socket.

Step 03: Insert the car key into the ignition cylinder and change it to “On”. For brand OBD2 equipment, you need to turn on the engine and invite it to idle.

Step 04: Turn on these devices, if this does not automatically activate itself.

Step 05: Enter the command to “read” or even “scan” the system diagnostics. How exactly to do this depends on the brand of the OBD2 device you are using. The design button changes from design to model, plus some devices can work with a menu system. A guide to getting the correct code will be in your device’s manual.

Step 06: Read through the hassle code on the reading screen of your device. Duplicate the code types down on a sheet related to paper. Some devices come with a USB port and can be connected directly to certain types of computers via USB cable. If you have this experienced OBD2 scanner, connect the device between the desktop in the scanner’s manual.

Step 07: Find the trouble code in your device’s manual. Often, generic OBD2 codes can be found in an annex on the back. These are general requirements that are standardized for all OBD2 cars. Manufacturers also have a new supplement. Customer’s guide will not have these types of codes. You will have to search them on the web or in a maintenance manual for the particular vehicle.

Step 08: Transform the vehicle’s electrical system. In case you have to start the engine, turn it off. Disconnect the OBD2 scanner’s diagnostic cord to the socket and turn off the device.
Conclusion

Finally, I think the above tips will help you use the OBD2 scanner appropriately. Therefore, it is important that the Professional Car Diagnostic Tool is usually a great device to withstand your will. In case you are an expert in repairing mechanical problems or simply want to know something along with your car (rather than being cheated by the dick seller) then self I work and get today. The amount of money you can keep for long periods of time will not be a substitute.

Which Auto Scan Tool Is Best

6

What is a scan tool?

Best Professional Car Diagnostic Tool is used to diagnose and detect variety of internal problems or malfunctions that can occur within your vehicle. These codes give you incite as to what is wrong with the car and where the problem is located. There are three different types of OBD scanner devices.

The first is your basic code reader; this model is good for reading and clearing codes.

The second is a more advanced automotive scan tool that can view live and recorded data, provide access to bi-directional tests and controls, access extensive knowledge bases, and other more advanced functions. Lastly, factory scan tools which are made specifically for the original equipment manufacturer and covers all vehicles manufactured under that company.

Your basic code reader will normally only have a couple buttons and cost you anywhere between $50-$100. It will be fine for reading standard diagnostic trouble codes and clearing them, but will not have vehicle specific or enhanced codes that a more advanced scan tool would have. A more Advance Engine Diagnostic Tool can run you anywhere from $1,000-$12,000 depending on the features, adapters and cables that may be bundled with it; but it’s functionality is far superior to your basic scan tool. There are also factory specific scan tools available that get up there is cost but may be worth it, depending on what you or your shop deals with on a daily basis.

Choosing the right Scan Tool

As with cars, there are many different options and tiers available when choosing a scan tool. You need to consider the ability to work on pre OBD–II vehicles, screen size and resolution, bundling options, bluetooth capabilities, platform needed, onboard memory, as well as, battery life and power source. For example, if you work on classic or antique cars you will want the ability to work on pre OBD-II vehicles. If you want to fine-tune your cars performance you’ll need a more advanced scan tool. It all depends on what you intend on using it for. The next time you are in the market for scan tool check out http://www.cnautotool.com/ for a wide variety of options and factory specific models.

How to Solve the Problem for GM MDI

There have many situations cant use GM MDI , when you have some troubles to use the tool ,  you should reboot the MDI software and do the Self Test first . Please check the bellowing 4 issues for GM MDI :

1. “MDI DOES NOT PASS SELF TEST”

If you meet this problem, it indicates that there is an internal problem in the MDI, you need to connect the MDI to a PC by using the USB and do the software recovery procedure or you can contact your local customer support center for help.



2. “MDI ERROR LED LIGHTS AFTER POWER ON”

This condition indicates that during power on, there has detected a problem. And the solution is to power down the MDI and verify that it has the same problem after you power up again, then connect the MDI to a PC by using the USB and do the software recovery process. Ask your local customer support center is ok.



3. “MDI FAILS TO POWER UP”

Normally speaking, Once the external power is applied,the MDI should power up. If the MDI from CnAutotool does not turn on, the first thing you need to do is to check the wall plug or power cable connections. Then try to supply power to the MDI from the two different power sources, the vehicle DLC connector and the AC 12-volt Adapter.



To solve this problem, you need to check and make sure that the cables are all attached to the MDI securely and the connector pins are all clean. If you are going to connect to the vehicle DLC connector, try to power from the AC 12-volt Adapter. And if you are going to connect to the AC 12-volt Adapter, you should try to power from the vehicle DLC connector. If your MDI still can’t power up, then you may have a problem with your MDI, you’d better contact with your local support center.



4. “MDI TURNS OFF IMMEDIATELY WHEN DISCONNECTED FROM THE VEHICLE”

Actually, after it is disconnected form the vehicle, the automotive scan tool MDI should stay on for a factory set time unless you press the power button. If the MDI turns off immediately once you disconnected it from the vehicle, you should power up the MDI and verify that it has the same problem when the power is removed, then replace the batteries and make sure they are properly installed. After these operation, if it still fails to be off correctly, your MDI may be damaged.



Any other issures for GM MDI Diagnostic Tool , welcome to contact us for technical support any time

Thank you

My using experience about Autel MaxiSYS Elite

30-1

I have been a Ford Master Technician for 30 years and used about every brand diagnostic scanner over the years and this one is hands down the best and most universal scanner I have used to date! Never once have I had an issue with the Blue Tooth connection between the scanner and the VCM II unlike what we use at Ford. Programs keys perfectly, bi-directional controls work flawless and is very fast processing of live data….WAY faster than Snap On Versus and the software especially for Ford is almost identical to Fords software with the IDS we use at the dealership…I actually prefer my Autel over the IDS now.

Autel Scanner would not connect with some vehicles, then with all vehicles. This cable solved the issues, and now all is well. As the site says, have a spare on hand. It will keep you from being out of the game and it is the common failure point due to USER “use” (or abuse…LOL)

The scanner can be charged with the charge cable or you can plug the charge cable into the stand and then simply set the scanner in and out of the stand as needed and it stays charged when docked between uses. I have it set up on my shops WiFi and it lets me know when there are updates and they update often which I also like.

The Autel MaxiSYS Elite can also be used as a tablet, has great resolution and does everything Snap On’s scanners do for a fraction of the price!

This is a nice heavy unit, not cheap and doesn’t feel cheap in your hands, comes with about every adapter you could ever need foreign and domestic for PCM hook up and can be easily expanded for oscilloscope and other options.

It is an amazing product, I would to thank to the people that helped me with my scanner I really appreciate it. The Professional Diagnostic Tool works very well and I’m happy with it. My only complaint is that I didn’t try one much sooner!!!
30-2

GM MDI software has updated to V2017.09 and “No Connection” error solved

1.Software update

1). Our GM MDI software has updated to V2017.09.It can support 2010-2017.09 year new cars.

2). If you think installation procedure is difficult for you,you can choose the GM MDI with Lenovo E49AL laptop,GM MDI software will be preinstalled in the Lenovo E49AL Laptop ,you can use it directly after receiving it.

25-1

2.“No Connection” error solved

Here is the detail explanation of GM MDI WIFI multiple diagnostic system “no connection” error and solution.

Problem:

When get the GM MDI tool from www.cnautotool.com connected with computer and plugged into car’s DLC OBD port, only two of the indicator light flashed while the other two are off. And then the GM MDI software system displayed “no connection” error message. See Fig.1 and Fig. 2.

25-2
25-3

Possible reason:
Improper operation procedure leads to the communication failure.

Solution:

Quit the GM MDI software and disconnect the GM MDI main unit
Open MDI Manager to check the driver
Open “Network setup” to check the network condition
If your MDI Manager shows a connection with your MDI and says software is compatible with pc, it is OK.
Reconnect the MDI device and load software again.

Follow the correction connection procedure and settings:

USB connection:

Once install and run the MDI manager, power up the MDI tester using the A/C 12-volt adapter. Then connect it to your computer with via USB cable.  The  automotive scan tool MDI appears in the application’s Explorer window where all the MDI units detected by your PC.

WIFI wireless connection:

1) Click MDI_Manager icon to start the MDI Manager software
2) Connect MDI with PC using USB cable
3) Power on the MDI by plugging in the A/C 12-volt adapter
4) Select and Connect to your MDI in the MDI Manager software MDI Explorer tab.
5) Select “Network Setup”
6) Select “Wireless” tab.
7) Select “Enable Wireless Interface check box in the Interface Control box to enable the interface. Once you enable the interface, the IP Address Configuration box and the Apply and Cancel buttons become active.
8) Select Obtain an IP address automatically if your LAN automatically assigns IP addresses. Otherwise enter the assigned IP Address and Subnet mask.
9) Select “Access Point” to start wireless access configuration.
10) If you are not within range of the access point you want to use, or the access point is not broadcasting its SSID, select the Enter Network Name [SSID]: radio button and type the network name.
11) If you are within range of your wireless access point, choose the Select from available network list radio button and then select Refresh to cause the MDI to search for wireless network signals. The detected networks are displayed in the Network Name box.
12) Select Configure after you have entered the network name
13) Enter the security setting that are required by your network, then select Next.
14) Select Yes to re-configure your MDI, or if you want to start over select No.
15) Select OK.
16) Choose the Properties tab to verify that the MDI is configured correctly.
17) Write down previous settings you did for future reference.

NOTE:

Installing the MDI Manager software installs certain utilities that are required for your TIS2Web programs to use the MDI. But, it is not necessary to start the MDI Manager software before using TIS2Web programs.

Ready to use CAT Electronic Technician 2017A V1.0

Caterpillar ET 2017A, Latest CAT ET Diagnostic Software to work with CAT/CAT3 Truck Scanner,With one free activation, can send software online,Supports Multi-languages.
20-1

View active and logged diagnostics.
View events where irregularities occurred and were logged by the ECM.
View the status of a group of parameters (temperatures, pressures, etc.) simultaneously.
Record and log performance data.
Graph a group of status parameters.
View the current configuration of an ECM.
Change ECM configurations.
Perform diagnostic tests.
Perform calibrations.
Print reports and diagnostic results.
In details…

Type of catalogue: Diagnostic Software
Make: Caterpillar
Region: WorldWide
Inclusive
languages: English, Chinese, Danish, French, German, Italian, Japanese, Portuguese, Russian, Spanish
Amount of
disks: 422 Mb, 1 CD
OS: Windows 7 32 bit, Wnidows 7 64 bit, Windows 8/8.1 32 bit, Windows 8/8.1 64 bit, Windows 10 32 bit, Windows 10 64 bit
We will remote help you installed and activation for 1 laptop by Teamviewer!
PC Requirements
Recommended Configurations

PC containing a 2.0 GHz dual-core processor
3GB RAM
3GB of available hard disk drive
DVD-ROM drive
15.4 inch XGA Screen (1280×1024 compatible)
Microsoft Windows? 7 Professional or Windows 8 Professional, Windows 10 Professional (Not tested with Home Edition) (Note: Windows 8 RT is not supported)
RS232 port with 16550AF UART or compatible (for use with CAT ET)
USB 1.1 or 2.0 port (for use with Comm Adapter 3)
Ethernet RJ45 connector
Built in pointing device or mouse
For security purposes, Microsoft Internet Explorer version 9 or newer is recommended.
Note: The most recent version of Microsoftò Internet Explorer may not be validated to work with the service tool from CnAutotool.com.

Caterpillar Communication Adapter III Kit

Caterpillar Comm Adapter III – diagnostic scanner interface is a CAT group dealer workshop diagnostic tool built to work with Caterpillar heavy vehicles and Caterpillar engines. It is the latest generation of the CAT Communication Adapter group and replaces the CAT Comm Adapter II & the old 466-6258 and 317-7487 tool number.

This is the only data transfer tool that will allow you to properly interact with the CAT engine on two data channels. This function is required for some CAT ET (Electronic Technician) functions.

At the moment, both CAT kits are available for purchase www.cnautotool.com.

The only difference with the new kit is that the adapter (box) will not pull the voltage to power itself from the computer’s USB Port.

The computer will recognize it as a connected device but Cat ET will not read the device unless it is plugged into a powered ECM.c Technician) functions.

The set includes:

1.CAT Comm Adapter III (part # 317-7485)
2.CD for installing the drivers
3.USB Cable (From device to your computer)
4.J1939/J1708 Cable (from device to your truck)
5.Hard Shell Case with foam inserts
6.Caterpillar ET 2017C Included

Caterpillar Electronic Technician (Cat ET) is a service tool designed to run on a personal computer (PC) under Microsoft Windows. It will communicate with the Electronic Control Modules (ECMs) through a communication data link thus allowing you to diagnose existing and potential problems, configure the product, and obtain data for analysis.

Check out this video to get more information about Caterpillar CommuniCATion Adapter 3 contents

With this service auto scanner diagnostic tool, you can:
View active and logged diagnostics
View events where irregularities occurred and were logged by the ECM
View the status of a group of parameters (temperatures, pressures, etc.) simultaneously
Record and log performance data
Graph a group of status parameters
View the current configuration of an ECM
Change ECM configurations
Perform diagnostic tests
Perform calibrations
Print reports and diagnostic results
For some machine and engine products, additional functionality has been included with the service tool program.

15-1 15-2 15-3 15-4 15-5 15-6

How-to Setup a MicroPod II for wiTECH 2

DESCRIPTION

If your dealership purchased a new microPOD and you would like to convert your existing microPOD for using with wiTECH 2.0 System, you need to download and install the microPOD Setup Utility to configure/setup your microPOD for Chrysler wiTech MicroPod 2.

For a video version of setting up a microPod 2 for wiTECH 2.0, please watch How To Set Up A New Device With wiTECH 2 (Note. You will have to be Logged into wiTECH 2.0 to view video)

NOTE: microPODs with a serial number beginning with “WFP” should NOT be used with this utility.

PROCEDURE

If you have a restricted network, you must first make sure that all sites listed below are enabled to be able to successfully use microPOD Setup Utility and the wiTECH 2.0 System.

1.mixpanel.com
2.bugsnag.com
3.fcawitech.com
4.chrysler.com
5.dealerconnect.com
6.jeep.com
7.witechsystem.com

Note: Please disable any Anti-Virus software that you have on your computer in order to allow the microPOD Setup Utility to install and run properly.

Steps to download and install the microPOD Setup Utility

IMPORTANT: Once the microPOD is configured using the microPOD Setup Utility, all the microPOD Wireless Settings will be deleted. You will be required to follow the instructions from the KB link titled “How to configure a Wireless Profile on a microPOD II”.

To download the application, please login to DealerCONNECT > Service > wiTECH Information > microPod Setup Utility

Step 1

Click on “Run” to begin the downloading process of microPOD Setup Utility.

10-1

Step 2

The install wizard will appear to install the wiTECH Driver x64 onto your computer if your PC has not been installed with wiTECH 1.0 application.

If the PC has been installed with wiTECH 1.0 App, you will not see the screen below and proceed to Step 6. Otherwise, click “Next” to proceed.

10-2

Step 3

Read the License Agreement carefully, and accept the terms in the license agreement. Then, click “Next” to continue.

10-3

Step 4

You are now ready to start the actual installation of the driver. You now need to click on “Install” for it to start.

10-4

Step 5

This will now install the wiTECH Driver x64. Once complete, the program will automatically proceed to the next step.

10-5

Step 6

Once the installation has completed, click “Finish”. Proceed to the following section, “Using the microPOD Setup Utility”.

10-6

Using the microPOD Setup Utility

NOTE: Please make sure that your computer is connected to the internet and the microPOD is connected to the computer via USB before starting this process. This application will help you configure your microPOD for wiTECH 2.0.

Step 1
Start microPOD Setup Utility by clicking the icon on the desktop:

10-07

If the microPOD Setup Utility that is installed is out of date, you will be forced to update to the newer version of the application.

10-7

Step 2

Please make sure your microPOD is connected to the PC via USB.

10-8

Step 2a

If you see the following screen you may not be connected to the internet, or have a firewall that blocks 1 or more of these websites.

10-9

Select “Continue” on the next screen for wiTECH 2.0 Device Setup and Configuration.

10-10

NOTE: If you only want to configure the wireless setting on a microPod device to use with wiTECH 2.0, click “Wireless Configuration” and follow instructions.

10-11

Select “Continue” on the next screen to begin attempting to connect to the microPOD device.

Step 3

Once your microPOD II is recognized by the utility, select “Continue” to proceed with the configuration.

10-12

NOTE: microPODs with a serial number beginning with “WFP” should NOT be used with this utility.

Step 4

If the utility does not find the microPOD device, please assure that the microPOD is connected via USB and click “Refresh”.

10-13

Step 5

The following screen will appear for up to 15 minutes while the microPOD device is being configured.

10-14

Step 6

The following screen will appear when the utility completed the configuration of microPOD for wiTECH 2.0 Application.

Note: After microPOD Setup Utility is ran, all existing wireless networks will be removed from the microPOD.

Important! Leave the microPod Setup Utility window running as you will be required to complete software updates to the microPod device before configuring the wireless.

Step 6a

Login into wiTECH 2.0 at https://login.n.fcawitech.com . The microPOD II that was just configured using the microPOD Setup Utility should appear in the  car diagnostic scanner wiTECH 2.0 discovery . You will need to update the operating system of your microPOD II before it can be used with wiTECH 2.0. Click “Continue”, and your web browser will redirect you to the page to download and install the operating system update as seen in the following step.

10-15

*NOTE: If microPOD II does not show up in discovery after a couple of minutes please power cycle your microPOD II by unplugging it and plugging it back in.

Step 7

Click “Update Now” and your microPOD II should continue to the update screen. Once updating, do not interrupt your microPOD II at any point until the update is complete.

10-16

*NOTE: This can take upwards of 9 minutes. It is normal activity for the microPOD II to reboot.

10-17

Step 8

Click “OK” and you will be navigated back to the wiTECH 2.0 discovery page. Your microPOD II should appear updated and ready for use.

10-18

Step 9

With the microPod Setup Utility still running, please follow the KB link listed below to configure wireless on the microPod device.
