BMW CAS3++ Add Smart Keys: Lonsdor K518 DONE

Tested successfully! Lonsdor K518ISE Key Programmer is able to add a smart key to BMW CAS3++.

Here’s the programming instruction in detail (with images)…

Lonsdor K518ise: Immobilizer – BMW

3+-obd-1

Select from type: CAS2/CAS3 series

3+-obd-3

Program key

3+-obd-4

Will start to make a dealer key

this can add one key (select blank position)
this can replace the original key (choose non-blank position)
this can generate a key via OBD or K518 slot
3+-obd-5

Pls press the Start button once
3+-obd-6

CAS part number: *******

CAS type: CAS++

For encrypted CAS. pls use an original key to switch ignition on

Pls back up eeprom data before any operation

Pls contact the dealer when key generation failed
3+-obd-7
Lonsdor read out frame number, cas part number, diagnostic code, key tooth code and remote key frequency and ignition

3+-obd-9

Reading ram, for about 1 min…

3+-obd-10

Remove the key from the ignition switch

For a smart key, take it outside the car

Ok to continue
3+-obd-11

Safety checking…

3+-obd-12

Reading key information…

3+-obd-13

Current CAS key position info: Key 3

3+-obd-14

Note: If the key is an original key, pls pre-pro-process it first.

If the key has been programmed but failed, pls do key unlocking and CAS key data restoring first

3+-obd-15

It’s a remote key

3+-obd-16

Pull K518 key slot to the right and insert the key to program (to identify id the key is legal and to pre-process

3+-obd-17

Current key is legal

Generating can be continued

3+-obd-18

Pls insert the key for programming into the car slot

3+-obd-19

Writing key data…

3+-obd-20

If for a remote of smart key, pls complete following steps:

take away the key from theition switch
re-insert the key into the ignition switch
press the start button

3+-obd-21

If the vehicle cannot be started, or the direction lock shows on the dashboard, pls synch ELV and DME accordingly

3+-obd-22

Writing key data – completed!

3+-obd-23

Job’s done!

2019 Lonsdor K518S VS 2017 K518ISE: wins in 3 packages

In short, the supported car models and capabilities of the Lonsdor K518S are subdivided from the Lonsdor K518ISE,
which has three package options. In other words, the Lonsdor K518ISE contains all the models and features of the
lonsdor K518S package. So that the users can choose the lowest-cost package according to their needs and make more
money.

lonsdor-518s-vs-k518ise-1

Lonsdor K518S package:

Package 1. SK213-B:

Host and adapters with free models (The workable car models are free lifetime)

Package 2. SK213-B + SK213-S1:

Hardware with free software + one-year update subscription (Addition: get first 6-month free update)

*** After one year expires, the payable options exist but need pay another one-year fee if you want to use again.

Package 3.SK213-B + SK213-S2

Hardware with free software + lifetime subscription [not incl. the cost of hardware and basic package (SK213-B) ]

Read: Lonsdor K518S function list

The part of the black words is lifetime free

The part of the red words is paid.

lonsdor-518s-vs-k518ise-2

Lonsdor K518ISE Package:

Package 1: SK213: Lonsdor K518ISE hardware with free software (free lifetime)

Package 2: SK213 + SK213-S

Lonsdor K518ISE hardware with free software + one-year subscription (630USD)

***After you pay 630USD, you can use all newest-released functions in the whole year,
and for the next year, you can continue use this part of functions updated in this year;
but for the next-year update, you have to pay.

Read: Lonsdor K518ISE latest update in October 2018

Read 2017 DACIA Dokker Pin and Add Spare Key with Lonsdor K518ISE Success

New test report:

Lonsdor K518ISE /K518S added a spare key (OEM key) on a 2017 DACIA Dokker 1.6 gasoline success
Perfect work, pincode reading and key programming.

The same for all Dacia(Renault) brand: Duster, Logan, Sandero, Dokker

?Thanks the feedback from Mr. Slavo Backov?
lonsdor-k518-2017-DACIA-Dokker-1 lonsdor-k518-2017-DACIA-Dokker-2
Step 1: Read Pin Code

Select Immobilizer->Dacia->Dokker->2012->Read Pin Code

lonsdor-k518-2017-DACIA-Dokker-3 lonsdor-k518-2017-DACIA-Dokker-4 lonsdor-k518-2017-DACIA-Dokker-5

Turn ON and OFF ignition switch, remove key

lonsdor-k518-2017-DACIA-Dokker-6
lonsdor-k518-2017-DACIA-Dokker-7

Read VIN
lonsdor-k518-2017-DACIA-Dokker-8 lonsdor-k518-2017-DACIA-Dokker-9
Reading data
lonsdor-k518-2017-DACIA-Dokker-10 lonsdor-k518-2017-DACIA-Dokker-11

Lonsdor read pin success

lonsdor-k518-2017-DACIA-Dokker-12

Step 2: Program key
lonsdor-k518-2017-DACIA-Dokker-13

Select Program Key in Lonsdor K518
lonsdor-k518-2017-DACIA-Dokker-14 lonsdor-k518-2017-DACIA-Dokker-15

Turn ON and OFF ignition switch, remove key
lonsdor-k518-2017-DACIA-Dokker-16 lonsdor-k518-2017-DACIA-Dokker-17

Insert original key and turn on ignition

lonsdor-k518-2017-DACIA-Dokker-18
lonsdor-k518-2017-DACIA-Dokker-19 lonsdor-k518-2017-DACIA-Dokker-20

Insert next key and turn ignition to ON position

lonsdor-k518-2017-DACIA-Dokker-21 lonsdor-k518-2017-DACIA-Dokker-22
Turn OFF and ON ignition
lonsdor-k518-2017-DACIA-Dokker-23 lonsdor-k518-2017-DACIA-Dokker-24

Current number of keys: 2

lonsdor-k518-2017-DACIA-Dokker-25

Program success
lonsdor-k518-2017-DACIA-Dokker-26 lonsdor-k518-2017-DACIA-Dokker-27

Test the remote control

lonsdor-k518-2017-DACIA-Dokker-28

Start engine with the new key.

Done.

Solution to the error caused by Lonsdor K518ISE update

This file offers the solutions to the errors caused by Lonsdor K518ISE update. Thanks to Lonsdor engineer and thanks to

obd2shop.co.uk translator.
lonsdor-k518ise-update-error-1

Solution:
Long press those two buttons which are marked in red at the same time.
lonsdor-k518ise-update-error-2

Choose “Uninstall the current APK”.
APK is uninstalled successfully.
lonsdor-k518ise-update-error-3 lonsdor-k518ise-update-error-4

Choose “Online update (New), you can tap the circle to check if there are newest updates.

lonsdor-k518ise-update-error-5

Kernel mirror image version under V2.26 needs to follow this step. After uninstalling APK successfully, click the arrow

in the middle of the screen. You will see “Online Update” in the bottom left corner, click it.
lonsdor-k518ise-update-error-6

Install the package after downloading. It might take a long time, please be patient. After installation, there are

“WIFI Setting” and “Update”, just click on “Update”. if it failed to update, change a network or change the

domain name according to the file of “WIFI Setting”.
If the device shows the interface below

lonsdor-k518ise-update-error-7

lonsdor-k518ise-update-error-8
lonsdor-k518ise-update-error-9

lonsdor-k518ise-update-error-10

lonsdor-k518ise-update-error-11 lonsdor-k518ise-update-error-12

Good luck!!!

Lonsdor K518 Program a Key and Remote for 2017 KIA Ceed: Done!

2017 KIA Ceed key and remote control programming… Lonsdor K518 work well!

80 bit immo system-pin code reading is not possible, do not read!

Got key by dump. you can key in pin code reading!

Only MK programmer knows! Abrites, Tango, Lonsdor I couldn’t read.

londor-k518-kia-add-key-1
londor-k518-kia-add-key-2

Then in Lonsdor:

Immobilizer – KIA – Select from vehicle – General area – Cee’d (JD) – 2013 – 2016

londor-k518-kia-add-key-3 londor-k518-kia-add-key-4

Two key fobs ready for programming

londor-k518-kia-add-key-5

Insert key and switch ignition on
londor-k518-kia-add-key-6

Enter pin codes

londor-k518-kia-add-key-7

Programming completed

Will program the next one
londor-k518-kia-add-key-8

Replace another new key and switch ignition on

londor-k518-kia-add-key-9 londor-k518-kia-add-key-10

Programming completed!

londor-k518-kia-add-key-11

Pls remove the key and wait for 5s

Programming completed!

londor-k518-kia-add-key-12

Test the new key on the car

It starts

londor-k518-kia-add-key-13 londor-k518-kia-add-key-14 londor-k518-kia-add-key-15
Done!
Lonsdor has a big success!

Lonsdor K518ISE About to Expire in 3 Days Error Solution

Problem:
Got an ultimatum if I don’t pay yearly subscription in the next 3 days I will not able to use pay modules in Lonsdor K518ISE, you get this message when you switch on the tool, how much is the yearly subscription?

Error:
“Advanced function is about to expire. Contact dealer to purchase and renew.
Excess time: 3 days 21 hours 1 minute”

Solution:
Pay for the Lonsdor K518ISE yearly subscription here:
After renew,go to check for update.
lonsdor-k518-check-for-update--00
Now the subscribed menu is renewed.

Lonsdor K518ISE and Lonsdor K518S, What’s Different?

Recently,Lonsdor company stop production for old Lonsdor K518ISE and release new one which can replace it —–New Lonsdor K518S.
So what’s the difference between K518ISE and K518S?
First of all,we should know Lonsdor Menus are divided into two parts: free menus and subscribed menus
1.Free menus are free use for lifetime.
2.Subscribed menus can be used for free for 180 days. You need to pay for them after the trial period .
For the first six months,both K518ISE and K518S can use all menus.
The difference is after the sixth month:
The free menu of K518ISE is more than K518S,so the price of K518S is cheaper than K518ISE.
The update subscription cost for K518ISE is same for every year—630USD.
The update subscription cost for K518S is not same.
–First Year Update Subscription for Lonsdor K518S Full Functions—800USD
–Second Year Update Subscription for Lonsdor K518S Full Functions—600USD
–Third Year Update Subscription for Lonsdor K518S Full Functions—300USD
–Lifetime Year Update Subscription for Lonsdor K518S Full Functions—3100USD
If you don’t want to pay,the device will not be locked ,you can still use free menus.
For K518S,you can choose device only (LONSDOR K518S Basic Version)or device plus update subscription(LONSDOR K518S Full Version)

How to Solve Lonsdor K518ise APP permission has expired

Displays the error message of Lonsdor K518S Key Programmer:

The APP permission has expired

Please connect network to sync automatically

How to Solve Lonsdor K518ise APP permission has expired-1 How to Solve Lonsdor K518ise APP permission has expired-2 How to Solve Lonsdor K518ise APP permission has expired-3
No worries!
How to Solve Lonsdor K518ise APP permission has expired-4

Issue will be resolved because it’s the internet problem only

Lonsdor K518ise Latest Update SCION

Lonsdor K518ISE Latest Update on March 14,2019, Update for Scion,Smart,Audi,Pontiac:

SCION\CH-R\2018\Smart key
SCION\CH-R\2018\mechanical key
SCION\FR-S\2013-2016\Smart key
SCION\FR-S\2013-2016\mechanical key
SCIONN\IA\2016-2018\Smart key
SCION\IM\2017-2018\mechanical key
SCION\IQ\12012-2015\mechanical key
SCION\TC\2005-2010\mechanical key
SCION\TC\2011-2015\Smart key
SCION\TC\2011-2015\mechanical key
SCION\XB\2012-2013\mechanical key
SCION\XB\2012\REMOTE
SCION\XD\2012-2013\mechanical key
SMART\BR450\2002-\IMMOBILIzer
SMART\BR452\2003-2006\IMMOBILIZER
SMART\Br454\2004-2006\Immobilizer
Audi\A4l\Immobilizer/Smart key
PONTIAC\Torrent\Immobilizer\2007-2009

you  bu



Lonsdor K518ISE SCION: 2011-2018 Models Enabled!

Lonsdor released the K518ISE update announcement on 14-03-2019, saying it can work with more SCION vehicles.

lonsdor-k518ise-scion-update-1

How to update SCION for Lonsdor K518ISE Key Programmer:

Close the device and open it, the update will come to you. All will be successfully

lonsdor-k518ise-scion-update-2

Lonsdor K518ise SCION car list:

SCION \CH-R\2018\ Smart key

SCION \CH-R\2018\Mechanical key

SCION \2013-2016\ Smart key

SCION \FR-S\2013-2016\Mechanical key

SCION \iA2016-2018\ Smart key

SCION \iM\2017-2018\Mechanical key

SCION \iQ\2012-2015\Mechanlcal key

SCION \tC\2005-2010\Mechanical key

SCION \tC\2011-2015\ Smart key

SCION \tC\2011-2015\Mechanical key

SCION \xB\2012-2013\Mechanical key

SCION \xB\2012\Remote

SCION \xD\2012-2013\Mechanical key

lonsdor-k518ise-scion-update-3

More Lonsdor update info released on 14-03-2019:

Software Update/Optimization Highlights

VAG IMMO K-Line 2&3 PIN code reading capability
BMW CAS1 Available as of now
BMW FEM/BDC latest variant indexes added as listed below
KIA/HYUNDAI Type 46 PIN code read for both Smart + Key-blade transponder types + implementation of LKE Emulator to enable PIN reading in case of AKL
Toyota selection menu by vehicle model
Porsche previously unsupported models AKL added via LKE Emulator in detail..

Lonsdor k518ise Software Optimization:

1.VWIMM02&IMM03 [Read PIN)

2.VW IMM04 Enable more dashboards to auto identify immo type

3.Skoda IMM02 ft IMM03 (Read PIN}

4.Skoda IMM04 Enable more dashboards to auto identify immo type

5.BMW CAS CAS1 is available; CAS2/CAS3 [Delete key)

6.BMW FEM/BOC Suport swfl 00002419 071 010 040.swfl 00002419 080 010 010

software version

7.Toyota: Optimize menu [Select from vehicle)

6.Oodge/Chrytler/JEEP ft Honda.

9 Hyundoi/Kle Optimize [Read 46 chip PIN) and [Read PIN code{46 smart

card)), support obtaining PIN via LKE decoding

10.BVD [General working key) .support generating SK via LKE to obtain PIN.

11.Porsche Optimize key programming procedure For Boxter(2005 2011)/Coy-

man(200S 2011)/997(2005-2010)/911(200S 2010).support bypass programming

with LKE

LKE Emulator Main Function

1.Features of Toyota/Lexus smart key all lost(5 emulators-in-1)

Dismantle-free

No need networking

Localized computing

2.Generate chip

LKE can be used to work as an emergency key to program when no dedicated

chip.

3-Copy chip

By collecting data to decode and copy chip, LKE currently supports some 46 and 4D chtp copy

4.Simulate and convert chip

Use [Generate chip] to make various chips, part of 40/46 and SKE Toyota  currently supported

5.Decode chip

Decode 46 and 4D chips to obtain SK.

6.identify ignition coil and key chip type(al) key lost)

7.As K518 helper:

Achieve programming key without PIN for Hyundai and Kia.

Achieve programming key without PIN for BYD

Achieve programming key without PIN for Porsche Cayman(2005-2010) and boxster

lonsdor-k518ise-scion-update-4 lonsdor-k518ise-scion-update-5 lonsdor-k518ise-scion-update-6
